Tired of being pushed around by water and moisture problems? Take back control with the W. R. MEADOWS complete moisture control package.

You've made a major investment in your building and that investment deserves the very best protection available. There's only one company that has consistently helped owners protect their buildings against the ingress of moisture through effective concrete waterproofing.

For over 85 years, W. R. MEADOWS has been recognized as the leader in developing and producing quality concrete waterproofing products for the construction industry. We have built a coveted reputation among architects, engineers and contractors for producing the highest quality products backed by 85+ years of experience.

How does moisture enter into my building?

Moisture is found in some form or another on every building site. The difference between a satisfied owner and a "problem" project is how you deal with this moisture. By developing systems that are designed to act together to provide complete protection, W. R. MEADOWS can help you design and build a structure that is protected.

Concrete Waterproofing SystemWhat makes up the total moisture control package?

W. R. MEADOWS manufactures a complete line of concrete waterproofing and moisture control products. When these products are used in combination as a system, they ensure that you have complete control of moisture migration in your facility.


Concrete Waterproofing Applications:

  • Bridges
  • Parking decks
  • Plaza decks
  • Structural slabs
  • Vehicular, utility and pedestrian tunnel projects
  • Hospitals
  • Schools
  • Office construction
  • Commercial projects
Resources:

Project Profiles:

Whatever your needs...
We have the solution.


Concrete Waterproofing Project1

Concrete Waterproofing Request
Concrete Waterproofing Product

Concrete Waterproofing Product 2

View this image in full resolution (Waterproofing Brochure page 3)

Concrete Waterproofing Products

HYDRALASTIC 836 is a cold-applied, solvent-free, single-component waterproofing compound. It does not shrink, has a low volatile organic compound (VOC) content, and has a very low odor. It will not crack in extreme cold or slump due to softening at high temperatures.

MEL-ROL® LM is a single-component, polymer-modified, cold-applied, water-based, liquid waterproofing membrane ideal for below-grade horizontal and vertical seamless waterproofing applications. We have taken the same high quality rubber polymers found in MEADOWS' successful MEL-ROL "peel and stick" membrane, and converted them into a heavy bodied, high solids, quick drying liquid membrane.

MEL-ROL LM (ALL SEASON) can be used on new and remedial waterproofing applications on concrete or masonry block substrates. Application can be performed in colder weather when water-based products cannot be used.

MEL-ROL waterproofing system is a flexible, versatile, dependable, roll-type waterproofing membrane. It is composed of a nominally 56 mil thick layer of polymeric waterproofing membrane on a heavy-duty, 4 mil thick, cross-laminated polyethylene carrier film.

PRECON is used as a blindside mebrane in vertical applications where access to the positive side is limited. The membrane can also be used for horizontal applications for underslab waterproofing and vaporproofing.

MEL-PRIMETM is a ready-to-use primer available in solvent-based and water-based versions.

PROTECTION COURSE is a multi-ply, semi-rigid core composed of a mineral-fortified asphalt core formed between two outside layers of asphalt-impregnated reinforced mats.

PERMINATOR® underslab vapor barrier can also be used as a protection course for waterproofing membranes. The desired sheet lengths are cut to size and retained at the top of the waterproofing membrane by PERMINATOR TAPE or TERMINATION BAR. PERMINATOR 10 mil is also ideal for use over horizontal applications of MEL-ROL LM.

MEL-DRAINTM drainage board is designed to remove moisture from around footings and relieve hydrostatic head pressures. Eight versions are available.

TERMINATION BAR from W. R. MEADOWS is provided in 10' (3 m) lengths for your attachment needs.

MEL-DEKTM waterproofing system provides an excellent waterproofing membrane for bridges, parking decks or other vehicular traffic structures to be overlaid with an asphaltic concrete wearing course. Ideal for repair, maintenance or new construction applications.

Waterproofing Accessories Data Sheets
MEADOW-PATCH 5
MEADOW-PATCH 20
• DETAIL STRIP

MEL-DRAIN TOTAL-DRAIN – Prefabricated Soil Drain System

mel-drain-total-drain1

07 10 00No. 719-B   MEL-DRAIN™ TOTAL-DRAIN™PREFABRICATED SOIL DRAIN SYSTEM The MEL-DRAIN TOTAL-DRAIN sheet drain system combines any regular MEL-DRAIN sheet drain section with the unique TOTAL-DRAIN section. In the … [Read more...]

REINFORCING FABRIC HCR – Reinforcement Material

07 00 00No. 706-BRelated Content:Material Safety Data SheetREINFORCING FABRIC HCR Reinforcement MaterialDESCRIPTION REINFORCING FABRIC HCR is a spun-bonded polyester hot/cold reinforcing fabric.USES REINFORCING FABRIC … [Read more...]

BEM – One-Component Waterproofing Membrane

bem-concrete-sheet-waterproofing-membrane

07 13 26No. 710Related Content: Material Safety Data Sheet: (USA, Canada, French)BEM One-Component Waterproofing MembraneDESCRIPTION BEM is a one-component, cold-applied, non-slump waterproofing … [Read more...]

HYDRALASTIC 836 – Cold-Applied, Single-Component Waterproofing

fluid applied concrete waterproofing

07 14 16No. 709Related Content:Material Safety Data Sheet: USA, Canada, French Fluid-Applied Waterproofing InfoCAD Details Guide Specification, USAHYDRALASTIC 836 Cold-Applied, Single-Component … [Read more...]

Gem-Crete TWM PLUS – Traffic Waterproofing Membrane

07 18 00SpecificationGem-Crete® TWM Plus Traffic Waterproofing MembraneDESCRIPTION Basic Use Gem-Crete TWM PLUS is designed for waterproofing of light to medium traffic surfaces, including parking garages in new construction and restoration. … [Read more...]

CEM-KOTE CW Plus (Canada)

07 16 00Related Content:Guide SpecificationCEM-KOTE® CW PLUS (Canada) Capillary / Crystalline WaterproofingDESCRIPTION Basic Use Cem-Kote CW Plus is a crystalline (capillary) in-depth waterproofing for new or existing water storage and … [Read more...]

ADI-CON CW PLUS – Waterproofing Admixture for Concrete

07 16 16Related Content:Info PageADI-CON® CW PLUS Waterproofing Admixture for ConcreteDESCRIPTION Basic Use ADI-CON CW PLUS is an integral waterproofing, admixture for Portland cement based concrete and mortars.Composition … [Read more...]

CEM-KOTE CW PLUS – Capillary/Crystalline Waterproofing

07 16 16No. 702Related Content:Material Safety Data Sheet: (USA) Request Brochure Guide Specification, USACEM-KOTE® CW PLUS Capillary/Crystalline WaterproofingANSI/NSF Standard 61 Drinking Water System … [Read more...]

ADI-CON CW PLUS – Waterproofing Admixture for Concrete

07 16 16No. 703Related Content:Guide Specification Request BrochureInfo PageADI-CON® CW PLUS Waterproofing Admixture for ConcreteDESCRIPTION ADI-CON CW PLUS is a dry, free flowing powder containing a blend of inorganic and … [Read more...]

CEM-KOTE FLEX ST (Canada) – Flexible Cementitious Waterproofing

07 16 13Related Content:Material Safety Data Sheet: (USA, Canada) Guide Specification: (Standard, Restoration)CEM-KOTE® FLEX ST (Canada) Flexible Cementitious WaterproofingANSI/NSF Standard 61Drinking Water … [Read more...]

REINFORCING FABRIC NW – Waterproof Reinforcing Fabric

07 16 13No. 706-ARelated Content:Project ProfileREINFORCING FABRIC NW™ Waterproof Reinforcing FabricDESCRIPTION REINFORCING FABRIC NW is a non-woven polymeric reinforcing fabric. The product is made of a high quality, polymeric … [Read more...]

REINFORCING FABRIC HD

07 16 13No. 706Related Content:Project ProfileREINFORCING FABRIC HD® Reinforcing Fabric Heavy DutyDESCRIPTION REINFORCING FABRIC HD is made of a high quality polymeric fiber with superior durability, resistance to Portland cement, … [Read more...]

CEM-KOTE FLEX TC – Flexible Cementitious Thin Coating

07 16 13No. 707CEM-KOTE® FLEX TC Flexible Cementitious Thin CoatingDESCRIPTION CEM-KOTE FLEX TC is a highly flexible, hydraulic cement based, two-component system, consisting of a dry Component A and a liquid Component B.USES CEM-KOTE FLEX TC … [Read more...]

CEM-KOTE FLEX ST – Flexible Cementitious Waterproofing

07 16 13No. 704Related Content:Material Safety Data Sheet: (Comp. A, Comp. B, Canada) Request BrochureGuide Specification: Standard, Restoration Project ProfilesCEM-KOTE® FLEX ST Flexible Cementitious … [Read more...]

CEM-KOTE FLEX PLUS – Flexible Cementitious Waterproofing

07 16 00CEM-KOTE® FLEX PLUS Flexible Cementitious WaterproofingFEATURESExcellent flexibility at low temperatures Substrate crack spanning, up to 2.5 mm Superior waterproofing (negative & positive) Long term crack resistance Excellent salt … [Read more...]

CEM-KOTE FLEX CR (Canada) – Cementitious Waterproofing

07 16 00 DATA SHEET NO. 813818115Related Content:Guide Specification, CanadaCEM-KOTE® FLEX CR (Canada) Flexible, Chemical Resistant, Cementitious WaterproofingPRODUCT DESCRIPTION Basic Use CEM KOTE FLEX CR is designed for waterproofing and … [Read more...]

CEM-KOTE FLEX CR – Cementitious Waterproofing

07 16 00No. 705Related Content:Guide Specification, USA Request BrochureCEM-KOTE® FLEX CR Flexible, Hydrogen-Sulfide-Resistant, Cementitious WaterproofingDESCRIPTION CEM-KOTE FLEX CR is a highly flexible, fiber-reinforced, hydraulic … [Read more...]

MEL-ROL LM (ALL SEASON) – Liquid Waterproofing Membrane

07 14 16No. 714-BRelated Content:Guide Spec, USA Guide Spec, Canada LEED Credit Chart Brochure RequestMEL-ROL® LM (ALL SEASON) Single-Component, Liquid-Applied, Polymer-Modified, Waterproofing … [Read more...]

MEL-ROL LM – Liquid Waterproofing Membrane

07 14 16No. 714-ARelated Content:Material Safety Data Sheet: (USA, Canada, French) Guide Spec, USA Guide Spec, CanadaBrochure Request Application DetailsMEL-ROL® LM Single-Component, Water-Based, Polymer-Modified, … [Read more...]

HRM 714 – Hot-Applied Rubberized Asphalt Membrane

hrm-714-rubberized-asphalt-membrane

07 14 13No. 708Related Content:Material Safety Data Sheet: (USA) CAD DetailsHRM 714 Hot-Applied Rubberized Waterproofing MembraneDESCRIPTION HRM 714 hot-applied rubberized asphalt waterproofing membrane is a 100% solids … [Read more...]

TERMINATION BAR

07 13 53No. 715Related Content: Material Safety Data Sheet: (USA, Canada)TERMINATION BARDESCRIPTION TERMINATION BAR is a multi-purpose, preformed, professional way to attach a wide variety … [Read more...]

POINTING MASTIC – Cold-Applied Sealing Compound

pointing-mastic-cold-applied-sealing-compound

07 13 53No. 740Related Content:Material Safety Data Sheet: (USA, Canada, French) Spanish Product DataLEED Credit Chart Project ProfilePOINTING MASTIC Cold-Applied, Single-Component Polymeric Sealing CompoundDESCRIPTION POINTING … [Read more...]

MEL-PRIME – Solvent-Based VOC Adhesive

07 13 53No. 751Related Content:Material Safety Data Sheet: (USA, Canada, French) Project ProfileMEL-PRIME™ Solvent-Based VOC AdhesiveDESCRIPTION MEL-PRIME is a solvent-based, ready-to-use adhesive for W. R. MEADOWS … [Read more...]

MEL-PRIME W/B – Water-Based Adhesive

07 13 26No. 752Related Content: Material Safety Data Sheet: (USA, Canada, French)MEL-PRIME™ W/B Water-Based AdhesiveDESCRIPTION MEL-PRIME W/B water-based adhesive is a ready-to-use … [Read more...]

OHIO TYPE III WATERPROOFING

07 13 26No. 701Related Content: Material Safety Data Sheet: (USA)  OHIO TYPE III WATERPROOFINGDESCRIPTION OHIO TYPE III WATERPROOFING is a heavy duty composite membrane used to … [Read more...]
